| Model | SHPP12 |
|---|---|
| Brand | SMOG-HOG |
| Warranty | One Year Manufacturing Defect |
| Origin | United States |
Features
- Highest efficiency removal of the widest range of particle size
- Easily cleaned and reusable ESP collection components eliminates filter replacement and disposal
- Low energy consumption
- Less frequent maintenance is required as collected liquid coalesces and drains off aluminium ESP collection components - always Maintains consistent airflow
- Collection of coils and coolants for reuse
- Highly effective collection of both oil-and water-based coolants
- Flexible intake configurations for generals’ area or source capture
- 22 different mist collection models to accommodate application needs
How Smog Hog Works
1. The electrostatic precipitator is usually installed on the inlet (suction) side before the fan. The contaminant-laden air passes through the Pre-filter where coarse particles are removed and optimally distributed in the housing.
2. The electrostatic field in the ionizer continuously positively charges the remaining fine particulate pollutants in fractions of a second.
3. The charged particles are then deposited on the Ground/Earthed after the collector, while the cleaned air discharges / exhausts out. The separating plates are designed in such a way that the contaminants run off easily, aiding self-cleaning of the electrostatic precipitator (optional in-place cleaning).
