Additional Information
| Model | K200M |
|---|---|
| Brand | Meiko |
| Size (LxWxH) mm | 1550 x 830 x 1400 |
| Capacity (ℓ) | 90 |
| Warranty | One Year Manufacturing Defect |
| Origin | Germany |
| Model | K200M | |
| Capacity | 130 ~ 200 baskets/h | |
| Voltage | 3 NPE 400 V, 50 Hz | |
| Water flow pressure | Minimum 2.5 bar Maximum 6.0 bar |
|
| Wash pump rating | 1.7 kW | |
| Pump throughout | 1020 litre/min | |
| Tank heating | 13.9 kW | |
| Tank capacity | 90 litre | |
| Final rinse water | 360 litre/h | |
| Booster heater | For warm water supply or heat recovery system | 16.7 kW |
| For cold water supply, no heat recovery | 33 kW | |
| Control | Sensor film panel | |
| Drain pipe work | Central | |
| Feeding tunnel | 250 mm | |
| Passing dimension (W x H) | 510 x 450 mm | |
| Machine dimension (L x W x H) | 1550 x 830 x 1400 mm | |
| Included Additional Accessory(ies) |
Table end switch for discharge roller table |
|
Features
- Electronic control panel and thermometers are conveniently located on the electrical cabinet door
- Low water consumption
- Noise reduction
- Energy saving
- Heat protection through double wall construction
- Reilable operation
- Long service life
- V-shaped tank with rounded edges - easy to clean
- Pump impeller and housing manufactured from heavy gauge stainless steel
- Pump housing has no edges or corners
- Large all-round suction area on tank floor
- Catch peg system with transport overload protection
- Machine operates independently of fluctuations in water pressure and creates air gap to prevent backflow
- 1 universal basket VKV 50/1
- 1 basket for small parts VKV 50/2
- Emergency- off switch
- CSS Plus system with booster pump 0.55kW
Manifold wash system
- Optimized cross-section and nozzle arrangements.
- Connection to rising pipe via a single stainless steel connection pipe inside the machine.
- Benefit: Remarkably easy to insert and remove both the top and bottom portions of the manifold wash system in this rack-type dishwasher. Nothing penetrates the rear wall – for leakage protection even after years of service.
